WS Series WiFi CMOS Digital Camera

Home Microscopy Digital Cameras & Tablets Wifi Cameras WS Series WiFi CMOS Digital Camera

WS Series WiFi CMOS Digital Camera

Wifi Cameras2021-08-03n50

Description

WS Series C-mount WIFI CMOS Camera

ICOE WS series is WIFI camera and it adopts ultra-high performance CMOS sensor as the image-picking device. WIFI is used as the data transfer interface.

When the WS camera is attached to the eyepiece of a microscope and started, it will and generates a WiFi signal for sending high-resolution images from a microscope to WiFi-enabled devices such as smartphones, tablets, and computers with iOS, Android, OS X, Linux and Windows operating systems, streaming images to up to six devices simultaneously.

The camera includes ImageView images software for quantifying, measuring, and annotating images and for using with an interactive white board. It also works with the free, downloadable ImageView app for viewing, capturing, and editing images.



Order Code Sensor & Size

(mm)

Pixel

(μm)

G Sensitivity

Dark Signal

FPS/Resolution Binning Exposure
WS-2PA 1080P/IMX222(C)
1/2.8″(5.38×3.02)
2.8×2.8 510mV with 1/30s
0.15mv with 1/30s
25@1920×1080 1×1 0.059ms~1941ms
WS-09A
(Suspended)
720P/MT9P001(C)
1/2.5″(5.63×3.17)
2.2×2.2 1.0 V/lux-sec
61dB
43dB
30@1280×720 2×2 0.21ms~200ms
WS-09B 720P/MT9P001(C)
1/2.5″(5.63×3.17)
2.2×2.2 1.0 V/lux-sec
61dB
43dB
10@1280×720 2×2 Auto
WS-03PA 0.3M/MT9V011(C)
1/4″(3.58×2.69)
5.6×5.6 1.9V/lux-sec
60dB
45dB
25@640×480 1×1 Auto



Other Hardware Configuration

Spectral Range 380-650nm (with IR-filter)
White Balance ROI White Balance/Manual Temp-Tint Adjustment
Color Rendering Technique Ultra Fine Color Engine
Capture/Control SDK Windows/Linux/macOS/Android Multiple Platform SDK(Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc);
Recording System Still Picture and Movie
Maximum Connected Device <=3
Cooling System* Natural



Operation Environment

Operating Temperature -10℃~ 50℃
Storage Temperature -20℃~ 60℃
Operating Humidity 30~80%RH
Storage Humidity 10~60%RH
Power Supply USB Power Adaptor, Not Recommend for PC USB Port



Software Environment

Operating System Support Microsoft Windows XP / Vista / 7 /8 /10 (32 & 64 bit)
IOS IPAD or IPhone, Android PAD and Phone
PC Requirements CPU: Equal to Intel Core2 2.8GHz or Higher
Memory: 2GB or More
WIFI Adapter with DHCP Enabled
Display: 17″ or Larger
CD-ROM
PAD IPAD or PAD with Android System
Mobile Phone IPhone or Smart Phone with Android System
