Description
Product Specifications
| Model | UD65H2M | ||
| Lens Parameter | Zoom magnification: | 0.6X-5X | ● |
| Working distance: | 86mm | ● | |
| Field of view: | 19mm x 11.5mm – 2.5mm x 1.5mm | ● | |
| Magnification: | 27X-230X (24-inch monitor) | ● | |
| Camera Parameter | Sensor: | 1/1.2″ CMOS, 2 MP | ● |
| Resolution: | 1920 x 1080 | ● | |
| Sensor: | 1/1.2″ CMOS | ● | |
| Pixel size: | 3.75 x 3.75um | ● | |
| Frame: | 60fps | ● | |
| Output: | High resolution HDMI output | ● | |
| Other interface | 2 USB ports (USB disks/Mouse) | ● | |
| Storage function: | Storage photo and video to USB disks | ● | |
| Mouse | Via USB port to USB mouse | ● | |
| Chip structure | FPGA+ARM | ● | |
| Operation system | LINUX3.10 | ● | |
| Main frequency speed | 1Ghz | ● | |
| Suppress glare | Continuously adjustable | ● | |
| Edge enhancement | Adjustable | ● | |
| Core structure | Dual-core Cortex-A9 | ● | |
| Light source parameeter: | Emitting color | Pure white (color can be customized) | ● |
| Number of LEDs | 52 LEDs (F3) | ● | |
| Illuminance | 8000-9000mcd | ● | |
| Wavelength | 455-457.5nm | ● | |
| Input voltage | AC110-240V | ● | |
| Output voltage | 12V | ● | |
| Brightness | Continuously adjustable, when the LED light source brightness is adjusted, the color temperature remains unchanged, and the brightness can be adjusted from 0 to 100% | ● | |
| Output power | 3-5W | ● | |
| Dimensions and specifications | Inner diameter 32mm, outer diameter 58mm, height 25mm | ● | |
| Stand Parameter: | Focusing method | Electric focus | ● |
| Center distance | 145mm | ● | |
| Column height | 318mm | ● | |
| Column diameter | 32mm | ● | |
| Base plate size | 330mm x 300mm | ● | |
| Focusing range | 40mm | ● | |
| Accuracy | 0.002mm | ● | |
| Adjustment resolution | 0.25um | ● | |
| Computer: | Computer with software | ● | |
| Monitor: | 24″ Monitor | ○ | |
