Description
1). GT Graphics Accelerated Microscope Camera
Innovative technology, the USB2.0 frame rate is greatly improved whilst maintaining the fidelity of the original image output. Simple and economical microscopy imaging.
2). Uncompressed data output, image quality is guaranteed
Innovative technology brings high-speed experience. At the same time, the GT also guarantees high-quality image output, 2 MP, 5 MP, 12 MP uncompressed resolution output, and integrates ICOE perfect color reproduction algorithm to bring super economic microscopy imaging and a high performance experience.
3). Minimalist operation mode, works more efficiently!
Using ICOE new Capture 2.1“image capture – processing – measuring – reporting” workflow software, the interface is simple, the function definition is clearer, and the intelligent image processing algorithms are implemented, the work is more efficient!
Note: The GT-12 equipped Capture V2.1 software does not include dark field image processing, real-time image stitching, and real-time depth of field fusion.
Product Specifications
| Model | GT-12 |
| Sensor type | CMOS |
| Sensor size | 1/2.33″ |
| Resolution | 12MP, 4000X3000 |
| Pixel size (μm) | 1.335μmx1.335μm |
| Frame | 15fps |
| Color/Mono | Color |
| Shutter mode | Rolling |
| Exposure mode | Auto/Manual |
| Picture format | TIFF/JPG/PNG/DICOM |
| Operating system | Windows 7/8/10, Mac |
| PC software | Capture 2.1 |
| SDK | C/C++, C#, Directshow |
| Optical interface | C Mount |
| Data interface | USB2.0 |
| Operating temperature | 0-40℃ |
| Operating humidity | 10%-85% |
| Camera size | 68 x 68 x 42.5mm |
| Camera weight | 253g |
