Description
Features
- Number of sections: Section and trimming counts are clearly displayed.
- The memory position: Multiple memory positions of sample holder
- Quick Positioning: One click to return to the user-defined position.
- Voice prompt: Alarms when sample holder travels approach displacement limit, helping identify travel distance
- OLEO display screen: Clear to see and easy to operate.
- Segmented positioning of blade holder: Three section quick positioning to maximize the utilization of blade edge
- Blade holder’s angle adjustment: The angle can be adjusted from 0 to 10 degrees, and the front and back position of the blade holder can be adjusted.
- High and low profile blade holder: Optional high and low profile blade holder
- Double Locking System: Upper lock enables quick operation; lower lock secures the handwheel at any position
Technical Specifications
| Section Thickness Range | Increment | Trimming Section Range | Increment | |
| 0.25~2.5µm | 0.25µm | 1~10µm | 1µm | |
| 2.5~5µm | 0.5µm | 10~20µm | 2µm | |
| 5~10µm | 1µm | 20~50µm | 5µm | |
| 10~30µm | 2µm | 50~150µm | 10µm | |
| 30~60µm | 5µm | 150~600µm | 50µm | |
| 60~100µm | 10µm |
| l Retraction range: 0~100µm (0 is off) 1-5-10-15-100 adjustable | l Nos. of section and trimming: 0~9999 |
| l Specimen feed: 30mm/Vertical stroke: 70mm | l Max. specimen size: 80x65mm |
| l Movement range of blade holder (left-to-right): 0~26mm | l Memory points: 2 points can be set |
| l Movement range of blade holder’s base (front-to-back): 0~65mm | l Precision error: ±1% |
| l Specimen orientation: Horizontal 8°, Vertical 8°, 360° Rotation (optional) | l Frequency: 50Hz / 60Hz |
| l Working voltage: AC 110-120V / AC 220V~240V | l Power draw: 100VA |
| l Feeding speed: 2000 µm/s | l Dimension: 595x465x295mm |
| l Feeding range small wheel: 100~1000µm/turn adjustable | l Net weight: 28kg |
